前言

• 深度卷积网络极大地推进深度学习各领域的发展，ILSVRC作为最具影响力的竞赛功不可没，促使了许多金典工作。我梳理了ILSVRC分类任务的各界冠军和亚军网络，简单介绍了它们的核心思想、网络框架及其实现。
  代码主要来自：https://github.com/weiaicunzai/pytorch-cifar100
• ImageNet和ILSVRC
  • ImageNet是一个超过15 million的图像数据集，大约有22,000类。
  • ILSVRC全称ImageNet Large-Scale Visual Recognition Challenge, 从2010年开始举办到2017年最后一届，使用ImageNet数据集的一个子集，总共有1000类。
• 历届结果

ps: 上表和真实指标可能略有差距。 + 评价指标
top1是指概率向量最大的作为预测结果，若分类正确，则为正确；top5则只要概率向量中最大的前五名里有分类正确的，则为正确。

LeNet

Gradient-Based Learning Applied to Document Recognition ### 网络架构

• 代码实现

import torch.nn as nn
import torch.nn.functional as func
class LeNet(nn.Module):
    def __init__(self):
        super(LeNet, self).__init__()
        self.conv1 = nn.Conv2d(1, 6, kernel_size = 5)
        self.conv2 = nn.Conv2d(6, 16, kernel_size = 5)
        self.fc1 = nn.Linear(16 * 16,  120)
        self.fc2 = nn.Linear(120, 84)
        self.fc3 = nn.Linear(84, 10)

    def forward(self, x):
        x = func.relu(self.conv1(x))
        x = func.max_pool2d(x, 2)
        x = func.relu(self.conv2(x))
        x = func.max_pool2d(x, 2)
        x = x.view(x.size(0), -1)
        x = func.relu(self.fc1(x))
        x = func.relu(self.fc2(x))
        x = func.fc3(x)
        return x

AlexNet

ImageNet Classification with Deep Convolutional Neural Networks ### 核心思想 + AlexNet相比前人有以下改进： + 采用ReLU激活函数 + 局部响应归一化LRN

    ![](https://imgs-heheomg.oss-cn-hangzhou.aliyuncs.com/blog_imgs/3.PNG)
+ Overlapping Pooling
+ 引入Drop out
+ 数据增强
+ 多GPU并行

网络架构

+ 代码实现

class AlexNet(nn.Module):
    def __init__(self, num_classes = NUM_CLASSES):
        super(AlexNet, self).__init()

        self.num_classes = num_classes

        self.features = nn.Sequential(
            nn.Conv2d(3, 96, kernel_size = 11, padding = 1),
            nn.ReLU(inplace = True),
            nn.MaxPool2d(kernel_size = 2),
            nn.Conv2d(96, 256, kernel_size = 3, padding = 1),
            nn.ReLU(inplace = True),
            nn.MaxPool2d(kernel_size = 2),
            nn.Conv2d(256, 384, kernel_size = 3, padding = 1),
            nn.ReLU(inplace = True),
            nn.Conv2d(384, 384, kernel_size = 3, padding = 1),
            nn.ReLU(inplace = True),
            nn.Conv2d(384, 256, kernel_size = 3, padding = 1),
            nn.ReLU(inplace = True),
            nn.MaxPool2d(kernel_size = 2),
        )
        self.classifier = nn.Sequential(
            nn.Dropout(),
            nn.Linear(256 * 2 *2, 4096),
            nn.ReLU(inplace = True),
            nn.Dropout(),
            nn.Linear(4096, 4096),
            nn.ReLU(inplace = True),
            nn.Linear(4096, num_classes),
        )

    def forward(self, x):
        x = self.features(x)
        x = x.view(x.size(0), 256 * 2 * 2)
        x = self.classifier(x)
        return x

实验结果

ZFNet

Visualizing and Understanding Convolutional Networks

核心思想

• 利用反卷积可视化CNN学到的特征
  • Unpooling: 池化操作不可逆，但通过记录池化最大值的位置可实现逆操作。
  • Rectification: ReLU
  • Fitering: 使用原卷积核的转置版本

网络架构

实验结果

• 特征可视化：Layer2响应角落和边缘、颜色连接；Layer3有更复杂的不变性，捕获相似纹理；Layer4展示了明显的变化，跟类别更相关；Layer5看到整个物体。

+ 训练过程特征演化：低层特征较快收敛，高层到后面才开始变化。上面每层从左到右训练次数为1，2，5，10，20，30，40，64个epoch。

+ 特征不变性：小变换在模型第一层变化明显，但在顶层影响较小。网络输出对翻转和缩放是稳定的，但除了旋转对称性的物体，输出对旋转并不是不变的。 + 遮挡敏感性： 当对象被遮挡，准确性会明显下降 + ImageNet结果

VGG

Very Deep Convolutional Networks for Large-Scale Image Recognition ### 核心思想 + 重复使用3x3卷积和2x2池化增加网络深度。

网络架构

• VGG19表示19层conv或fc,参数量较大。

代码实现

cfg = {
    'A' : [64,     'M', 128,      'M', 256, 256            'M', 512, 512,           'M', 512, 512,           'M'],
    'B' : [64, 64, 'M', 128, 128, 'M', 256, 256,           'M', 512, 512,           'M', 512, 512,           'M'],
    'D' : [64, 64, 'M', 128, 128, 'M', 256, 256, 256,      'M', 512, 512, 512,      'M', 512, 512, 512,      'M'],
    'E' : [64, 64, 'M', 128, 128, 'M', 256, 256, 256, 256, 'M', 512, 512, 512, 512, 'M', 512, 512, 512, 512, 'M'],
}

def vgg19_bn():
    return VGG(make_layers(cfg['E'], batch_norm=True))

class VGG(nn.Module):
    def __init__(self, features, num_class = 100):
        super().__init()
        self.features = features

        self.classifier = nn.Sequential(
            nn.Linear(512, 4096),
            nn.ReLU(inplace=True),
            nn.Dropout(),
            nn.Linear(4096, 4096),
            nn.ReLU(inplace=True),
            nn.Dropout(),
            nn.Linear(4096, num_class)
        )

    def forward(self, x):
        output = self.features(x)
        output = output.view(output.size()[0], -1)
        output = self.classifier(output)
        return output

    def make_layers(cfg, batch_norm=False):
        layers = []

        input_channel = 3
        for l in cfg:
            if l == 'M':
                layers += [nn.MaxPool2d(kernel_size = 2, stride = 2)]
                continue

            layers += [nn.Conv2d(input_channel, l, kernel_size = 3, padding = 1)]

            if batch_norm:
                layers += [nn.BatchNorm2d(l)]

            layers += [nn.ReLU(inplace = True)]
            input_channel = 1
        return nn.Sequential(*layers)

实验结果

GoogLeNet(V1)

Going Deeper with Convolutions

ps: https://blog.csdn.net/weixin_39953502/article/details/80966046

核心思想

• 提出Inception模块，可在保持计算成本的同时增加网络的深度和宽度。

代码实现

class Inception(nn.Module):
    def __init__(self, input_channels, n1x1, n3x3_reduce, n3x3, n5x5_reduce, n5x5, pool_proj):
        super().__init__()

        #1x1conv branch
        self.b1 = nn.Sequential(
            nn.Conv2d(input_channels, n1x1, kernel_size = 1),
            nn.BatchNorm2d(n1x1),
            nn.ReLU(inplace = True)
        )

        #1x1conv -> 3x3conv branch
        self.b2 = nn.Sequential(
            nn.Conv2d(input_channels, n3x3_reduce, kernel_size = 1),
            nn.BatchNorm2d(n3x3_reduce),
            nn.ReLU(inplace=True),
            nn.Conv2d(n3x3_reduce, n3x3, kernel_size=3, padding = 1),
            nn.BatchNorm2d(n3x3),
            nn.ReLU(inplace=True)
        )

        # 1x1conv -> 5x5conv branch
        # we use 2 3x3 conv filters stacked instead
        # of 1 5x5filters to obtain the same receptive
        # field with fewer parameters
        self.b3 = nn.Sequential(
            nn.Conv2d(input_channels, n5x5_reduce, kernel_size = 1),
            nn.BatchNorm2d(n5x5_reduce),
            nn.ReLU(inplace = True),
            nn.Conv2d(n5x5_reduce, n5x5, kernel_size = 3, padding = 1),
            nn.BatchNorm2d(n5x5, n5x5),
            nn.ReLU(inplace=True),
            nn.Conv2d(n5x5, n5x5, kernel_size = 3, padding = 1),
            nn.BatchNorm2d(n5x5),
            nn.ReLU(inplace = True)
        )

        # 3x3pooling ->1x1conv
        # same conv
        self.b4 = nn.Sequential(
            nn.MaxPool2d(3, stride = 1, padding = 1),
            nn.Conv2d(input_channels, pool_proj, kernel_size = 1),
            nn.BatchNorm2d(pool_proj),
            nn.ReLU(inplace = True)
        )

    def forward(self, x):
        return torch.cat([self.b1(x), self.b2(x), self.b3(x), self.b4(x)], dim = 1)

网络架构

高清图看论文

代码实现

def googlenet():
    return GoogleNet()

class GoogleNet(nn.Module):
    def __init__(self, num_class=100):
        super().__init__()
        self.prelayer = nn.Sequential(
            nn.Conv2d(3, 192, kernel_size = 3, padding = 1),
            nn.BatchNorm2d(192),
            nn.ReLU(inplace = True)
        )

        # although we only use 1 conv layer as prelayer,
        # we stil use name a3, b3...
        self.a3 = Inception(192, 64, 96, 128, 16, 32, 32)
        self.b3 = Inception(256, 128, 192, 32, 96, 64)

        # In general, an Inception network is a network consisting of
        # modules of the above type stacked upon each other, with occasional
        # max-pooling layers with stride 2 to halve the resolution of the grid
        self.maxpool = nn.MaxPool2d(3, stride=2, padding = 1)

        self.a4 = Inception(480, 192, 96, 208, 16, 48, 64)
        self.b4 = Inception(512, 160, 112, 224, 24, 64, 64)
        self.c4 = Inception(512, 128, 128, 256, 24, 64, 64)
        self.d4 = Inception(512, 112, 144, 288, 32, 64, 64)
        self.e4 = Inception(528, 256, 160, 320, 32, 128, 128)

        self.a5 = Inception(832, 256, 160, 320, 32, 128, 128)
        self.b5 = Inception(832, 384, 192, 284, 48, 128, 128)

        # input feature size: 8*8*1024
        self.avgpool = nn.AdaptiveAvgPool2d((1,1))
        self.dropout = nn.Dropout2d(p=0.4)
        self.linear = nn.Linear(1024, num_class)

    def forward(self, x):
        output = self.prelayer(x)
        output = self.a3(output)
        output = self.b3(output)

        output = self.maxpool(output)

        output = self.a5(output)
        output = self.b5(output)

        # It was found that a move from fully connected layers
        # to average pooling imporved the top-1 accuracy by about 0.6%,
        # however the use of dorpout remained essential even after
        # removing the fully connected layers.
        output = self.avgpool(output)
        output = self.dropout(output)
        output = output.view(output.size()[0], -1)
        output = self.linear(output)

        return output

实验结果

ResNet

Deep Residual Learning for Image Recognition

核心思想

• 为了解决深层网络难以训练的问题，提出了残差模块和深度残差网络
  • 假设网络输入是x，经学习的输出是F(x),最终拟合的目标是H(x)。
  • 深层网络相比浅层网络有一些层是多余的，若让多余层学习恒等变换H(x)=x，那么网络性能不该比浅层网络要差。
  • 传统网络训练目标H(x)= F(x), 残差网络训练目标H(x)=F(x) + x
  • 为了学习恒等变换，传统网络要求网络学习F(x) = H(x) = x， 残差网络只需学习F(x) = H(x)-x = x-x = 0. 残差学习之所以有效是因为让网络学习F(x) = 0比学习F(x)=x要容易。

• bottleneck

• 代码实现

class BottleNeck(nn.Module):
    """
    Residual block for resnet over 50 layers
    """
    expansion = 4
    def __init__(self, in_channels, out_channels, stride = 1):
        super().__init__()
        self.residual_function = nn.Sequential(
            nn.Conv2d(in_channels, out_channels, kernel_size= 1, bias = False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU(inplace=True),
            nn.Conv2d(out_channels, out_channels, stride = stride, kernel_size=3, padding = 1, bias = False),
            nn.BatchNorm2d(out_channels),
            nn.ReLU(inplace=True),
            nn.Conv2d(out_channels, out_channels*BottleNeck.expansion, kernel_size = 1, bias= False),
            nn.BatchNorm2d(out_channels * BottleNeck.expansion),
        )

        self.shortcut = nn.Sequential()

        if stride != 1 or inchannels != out_channels * BottleNeck.expansion:
            self.shortcut = nn.Sequential(
                nn.Conv2d(in_channels, out_channels * BottleNeck.expansion, stride = stride, kernel_size = 1, bias=False),
                nn.BatchNorm2d(out_channels*BottleNeck.expansion)
            )
    def forward(self, x):
        return nn.ReLU(inplace = True)(self.residul_function(x) + self.shortcut(x))

网络架构

代码实现

def resnet152():
    '''return a ResNet 152 object
    '''
    return ResNet(BottleNeck, [3, 8, 36, 3])

class ResNet(nn.Module):
    def __init__(self, block, num_block, num_classes = 100):
        super().__init__()

        self.in_channels = 64

        self.conv1 = nn.Sequential(
            nn.COnv2d(3, 64, kernel_size = 3, padding = 1, bias = False),
            nn.BatchNorm2d(64),
            nn.ReLU(inplace = True)
        )
        #we use a different inputsize than the original paper
        # so conv2_x's stride is 1
        self.conv2_x = self._make_layer(block, 64, num_block(0), 1)
        self.conv3_x = self._make_layer(block, 128, num_block[1], 2)
        self.conv4_x = self._make_layer(block, 256, num_block[2], 2)
        self.conv5_x = self._make_layer(block, 512, num_block[3], 2)
        self.avg_pool = nn.AdaptiveAvgPool2d((1, 1))
        self.fc = nn.Linear(512, * block.expansion, num_classed)

    def _make_layer(self, block, out_channels, num_blocks, stride):
        """make resnet layers(by layer i didnt mean this 'layer' was the
        same as a neuron netowork layer, ex. conv layer), one layer may
        contain more than one residual block

        Args:
            block: block type, basic block or bottle neck block
            out_channels: output depth channel number of this layer
            num_blocks: how many blocks per layer
            stride: the stride of the first block of this layer

        Return:
            return a resnet layer
        """

        # we have num_block blocks per layer, the first block
        # could be 1 or 2, other blocks would always be 1
        strides = [stride] + [1] * (num_blocks - 1)
        layers = []
        for stride in strides:
            layers.append(block(self.in_channels, out_channels, stride))
            self.in_channels = out_channels * block.expansion

        return nn.Sequential(*layers)

    def forward(self, x):
        output = self.conv1(x)
        output = self.conv2_x(output)
        output = self.conv3_x(output)
        output = self.conv4_x(output)
        output = self.conv5_x(output)
        output = self.avg_pool(output)
        output = output.view(output.size(0), -1)
        output = self.fc(output)

        return output

实验结果

ResNext

Aggregated Residual Transformations for Deep Neural Networks

核心思想

• 通过重复构建block来聚合一组相同拓扑结构的特征，并提出一个新维度"cardinality"。
• resNext结合了VGG, ResNet重复堆叠模块和Inception的split-transform-merge的思想。

以下三者等价，文章采用第三种实现，其使用了组卷积

• 代码实现

CARDINALITY = 32
DEPTH = 4
BASEWIDTH = 64

class ResNextBottleNeckC(nn.Module):
    def __init__(self, in_channels, out_channels, stride):
        super().__init__()

        C = CARDINALITY #How many groups a feature map was splitted into

        #"""We note that the input/output width of the template is fixed as
        #256-d (Fig. 3), We note that the input/output width of the template
        #is fixed as 256-d (Fig. 3), and all widths are dou- bled each time
        #when the feature map is subsampled (see Table 1)."""
        D = int(DEPTH * out_channels / BASEWIDTH) #number of channels per group
        self.split_transforms = nn.Sequential(
            nn.Conv2d(in_channels, C * D, kernel_size=1, groups=C, bias=False),
            nn.BatchNorm2d(C * D),
            nn.ReLU(inplace=True),
            nn.Conv2d(C * D, C * D, kernel_size=3, stride=stride, groups=C, padding=1, bias=False),
            nn.BatchNorm2d(C * D),
            nn.ReLU(inplace=True),
            nn.Conv2d(C * D, out_channels * 4, kernel_size=1, bias=False),
            nn.BatchNorm2d(out_channels * 4),
        )

        self.shortcut = nn.Sequential()

        if stride != 1 or in_channels != out_channels * 4:
            self.shortcut = nn.Sequential(
                nn.Conv2d(in_channels, out_channels * 4, stride=stride, kernel_size=1, bias=False),
                nn.BatchNorm2d(out_channels * 4)
            )

    def forward(self, x):
        return F.relu(self.split_transforms(x) + self.shortcut(x))

网络架构

• 代码实现 以下部分跟ResNet基本一致，重点关注ResnextBottleNeckC的实现

def resnext50():
    """ return a resnext50(c32x4d) network
    """
    return ResNext(ResNextBottleNeckC, [3, 4, 6, 3])

class ResNext(nn.Module):
    def __init__(self, block, num_blocks, class_names=100):
        super().__init__()
        self.in_channels = 64

        self.conv1 = nn.Sequential(
            nn.Conv2d(3, 64, 3, stride=1, padding=1, bias=False),
            nn.BatchNorm2d(64),
            nn.ReLU(inplace=True)
        )
        self.conv2 = self._make_layer(block, num_blocks[0], 64, 1)
        self.conv3 = self._make_layer(block, num_blocks[1], 128, 2)
        self.conv4 = self._make_layer(block, num_blocks[2], 256, 2)
        self.conv5 = self._make_layer(block, num_blocks[3], 512, 2)
        self.avg = nn.AdaptiveAvgPool2d((1, 1))
        self.fc = nn.Linear(512 * 4, 100)

    def forward(self, x):
        x = self.conv1(x)
        x = self.conv2(x)
        x = self.conv3(x)
        x = self.conv4(x)
        x = self.conv5(x)
        x = self.avg(x)
        x = x.view(x.size(0), -1)
        x = self.fc(x)
        return x

    def _make_layer(self, block, num_block, out_channels, stride):
        """Building resnext block
        Args:
            block: block type(default resnext bottleneck c)
            num_block: number of blocks per layer
            out_channels: output channels per block
            stride: block stride

        Returns:
            a resnext layer
        """
        strides = [stride] + [1] * (num_block - 1)
        layers = []
        for stride in strides:
            layers.append(block(self.in_channels, out_channels, stride))
            self.in_channels = out_channels * 4

        return nn.Sequential(*layers)

实验结果

SENet

Squeeze-and-Excitation Networks

核心思想

• 卷积操作融合了空间和特征通道信息。大量工作研究了空间部分，而本文重点关注特征通道的关系，并提出了Squeeze-and-Excitation(SE)block，对通道间的依赖关系进行建模，自适应校准通道方面的特征响应。

• SE block Ftr表示transformation（一系列卷积操作）；Fsq表示squeeze，产生通道描述；Fex表示excitation，通过参数W来建模通道的重要性。Fscale表示reweight，将excitation输出的权重逐乘以先前特征，完成特征重标定。

• SE-ResNet Module

• 代码实现

class BottleneckResidualSEBlock(nn.Module):
    expansion = 4

    def __init__(self, in_channels, out_channels, stride, r=16):
        super().__init__()

        self.residual = nn.Sequential(
            nn.Conv2d(in_channels, out_channels, 1),
            nn.BatchNorm2d(out_channels),
            nn.ReLU(inplace=True),

            nn.Conv2d(out_channels, out_channels, 3, stride=stride, padding=1),
            nn.BatchNorm2d(out_channels),
            nn.ReLU(inplace=True),

            nn.Conv2d(out_channels, out_channels * self.expansion, 1),
            nn.BatchNorm2d(out_channels * self.expansion),
            nn.ReLU(inplace=True)
        )

        self.squeeze = nn.AdaptiveAvgPool2d(1)
        self.excitation = nn.Sequential(
            nn.Linear(out_channels * self.expansion, out_channels * self.expansion // r),
            nn.ReLU(inplace=True),
            nn.Linear(out_channels * self.expansion // r, out_channels * self.expansion),
            nn.Sigmoid()
        )

        self.shortcut = nn.Sequential()
        if stride != 1 or in_channels != out_channels * self.expansion:
            self.shortcut = nn.Sequential(
                nn.Conv2d(in_channels, out_channels * self.expansion, 1, stride=stride),
                nn.BatchNorm2d(out_channels * self.expansion)
            )

    def forward(self, x):

        shortcut = self.shortcut(x)

        residual = self.residual(x)
        squeeze = self.squeeze(residual)
        squeeze = squeeze.view(squeeze.size(0), -1)
        excitation = self.excitation(squeeze)
        excitation = excitation.view(residual.size(0), residual.size(1), 1, 1)

        x = residual * excitation.expand_as(residual) + shortcut

        return F.relu(x)

网络架构

• 代码实现

def seresnet50():
    return SEResNet(BottleneckResidualSEBlock, [3, 4, 6, 3])

class SEResNet(nn.Module):

    def __init__(self, block, block_num, class_num=100):
        super().__init__()

        self.in_channels = 64

        self.pre = nn.Sequential(
            nn.Conv2d(3, 64, 3, padding=1),
            nn.BatchNorm2d(64),
            nn.ReLU(inplace=True)
        )

        self.stage1 = self._make_stage(block, block_num[0], 64, 1)
        self.stage2 = self._make_stage(block, block_num[1], 128, 2)
        self.stage3 = self._make_stage(block, block_num[2], 256, 2)
        self.stage4 = self._make_stage(block, block_num[3], 516, 2)

        self.linear = nn.Linear(self.in_channels, class_num)

    def forward(self, x):
        x = self.pre(x)

        x = self.stage1(x)
        x = self.stage2(x)
        x = self.stage3(x)
        x = self.stage4(x)

        x = F.adaptive_avg_pool2d(x, 1)
        x = x.view(x.size(0), -1)

        x = self.linear(x)

        return x


    def _make_stage(self, block, num, out_channels, stride):

        layers = []
        layers.append(block(self.in_channels, out_channels, stride))
        self.in_channels = out_channels * block.expansion

        while num - 1:
            layers.append(block(self.in_channels, out_channels, 1))
            num -= 1

        return nn.Sequential(*layers)

• 实验结果

总结

• 小结
  1. LeNet[1998]：CNN的鼻祖。
  2. AlexNet[2012]：第一个深度CNN。
  3. ZFNet[2012]：通过DeconvNet可视化CNN学习到的特征。
  4. VGG[2014]：重复堆叠3x3卷积增加网络深度。
  5. GoogLeNet[2014]：提出Inception模块，在控制参数和计算量的前提下，增加网络的深度与宽度。
  6. ResNet[2015]：提出残差网络，解决了深层网络的优化问题。
  7. ResNeXt[2016]：ResNet和Inception的结合体，Inception中每个分支结构相同，无需人为设计。
  8. SENet[2017]：提出SE block，关注特征的通道关系。
• 经典模型结构中、参数对比
